High efficiency rebar tying machine

FOB Reference Price:Get Latest Price
  • 3 - 9 Sets
    $530.00
  • 10 - 29 Sets
    $500.00
  • >=30 Sets
    $480.00
Lead Time:
Quantity(Sets) 1 - 3 4 - 12 13 - 50 >50
Est. Time(days) 7 10 25 Negotiable
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Jiangxi, China
Brand Name:
WL
Model Number:
WL-400B
Type:
Power tool
Feature:
Automatic
Power Source:
Battery drive
Application:
Construction,building
Product Name:
Rebar Tying Machine
Max Tying Diameter:
40 mm
Battery type:
Li-ion DC14.4V(4.4AH)
Charge Time:
70 Minutes
Tying speed per knot:
0.75 Seconds
Ties Per Coil:
Approx.130ties(3turns)
Wire diameter:
0.8mm
Machine Size:
295mm*120mm*275mm
Supply Ability
Supply Ability:
3000 Set/Sets per Month Automatic Rebar Tying Machine
Packaging & Delivery
Packaging Details
Plastic box(inner packing) , Carton box(outer packing) , 3sets/carton
Port
Ningbo,Shenzhen
Picture Example:
package-img
package-img
Lead Time :
Quantity(Sets) 1 - 3 4 - 12 13 - 50 >50
Est. Time(days) 7 10 25 To be negotiated
Video Description
Product Description

Product Application

our rebar tying tools are extensively used in Concrete floors, Concrete foundations,Concrete walls, Precast Products, Swimming pool walls, Retaining walls, Underfloor heating.

Main Features

1) One hand operation-easy to handle

2) 5 times faster than hand tying

3) Li-ion higher capacity battery

4) Brushless twisting motor-long service life

5) Light weight & compact body



Automatic rebar tying machine
Model No.
wL-210B(Li-ino)
wL-400B(Li-ino)
Max Tying Diameter
21mm
40mm
Voltage & Capacity
DC14.4V(4.4AH)
DC14.4V(4.4AH)
Charge Time
Approx.70mins
Approx.70mins
Tying speed per knot
0.7 seconds
0.75 seconds
Ties per Charge
Over 3200ties
Over 3200 ties
Ties per Coil
Approx. 195ties(3turns)
Approx.130ties(3turns)
Turns per Tie
2turns/3turns
2turns/3turns
Length of Wire for Tying
            380mm/2 turns
550mm/3 turns
650mm/2 turns
750mm/3 turns
Wire Type
Black annealed wire or Galvanized wire
Black annealed wire or Galvanized wire
Net Weight
1.8kgs
1.9kgs
Dimension(L)X(W)X(H)
275mmX120mmX275mm
295mmX120mmX275mm

One set including

1pc Rebar tier machine.

2pc Battery pack.

1pc Quick charger.

  3pc Steel wire rolls.

GW of one set:7kgs

1pc Specification


1pc Inner hexagon spanner


1pc Sharp nose pliers


Packing size:45*34*13cm



Detailed Images





Name:Magnetic brake

Features:strong durability ,fast speed








Name:Brushless twisting motor

Features:Long service life,fast speed





Name:Fastner
Features:Made of copper or aluminum,quality assured
Our Company



Fuzhou ZhuoYuan Machine Co. Ltd is located in Jiangxi province,which is a professional manufacturer and supplier of automatic rebar tying machine.Our company was founded in 2014,have a complete and scientific quality management system.

Packing
Packaging
Size
295mm(L)*120mm(W)*275mm(H)
Weight
7.2kgs
Packaging Details
The normal package is plastic box(inner packing),carton box(outer packing).
3sets/cartons.
FAQ

1.Q: Are you a trading company or factory?
A: We are a factory

2.Q: Can you provide samples ?

A:Yes,We offer paid samples and we will return the sample fee to you when we receive the payment for your large order.

3.Q:How should I pay the freight?

A:After you place the order,we will make a proforma invoice to you and list the detailed cost.

4.Q:What is the terms of payment?

A:Pay 100% in advance for any order,other special circumstances excepted.

5.Q:Do you have after-sale service?

A:Yes,most parts have maintenance period,free of charge within warranty.
